FVP
14104020

第三方数据FVP : 14104020

Caliper
FVP : 14104020

Abutment Clips Included: Yes
Bleeder Install Thread Count in: 5.5
Bleeder Screw Included: Yes
Bleeder Screw Thread Diameter: 10.000 MM
Bleeder Screw Thread Size: M10-1.00
Bracket #: 743.04019
Caliper Casting Material: Cast Iron
Caliper Color: Gray
Caliper Manufacturer: ATE
Caliper Type: Floating
Casting Number: 475; D339
Inlet Fitting Type: Bubble
Inlet Thread Diameter: 10.000 MM
Inlet Thread Size: M10-1.00
Mounting Bracket Included: Yes
Mounting Hardware Included: No
Pad Wear Sensor Included: No
Pads Included: No
Piston Diameter: 54.000 MM
Piston Material: Steel
Piston Quantity: 1
Published Bore Size: 54
Rust Preventative Coating: Yes

适用车型

FIAT (1)

参考号

厂商	号码
OE	141-0402*
